bcm_rod.bcm_rod_arc Architecture Reference
structural description of ROD formatter More...
Inheritance diagram for bcm_rod.bcm_rod_arc:
Collaboration diagram for bcm_rod.bcm_rod_arc:
Components | |
| bcm_rod_treadmil | <Entity bcm_rod_treadmil> |
| treadmill, assembling packets | |
| bcm_rod_ram | <Entity bcm_rod_ram> |
| DP-RAM, store pkt. | |
| bcm_rod_formatter | <Entity bcm_rod_formatter> |
| formatter | |
Signals | |
| treadmil_data_output | std_logic_vector ( 31 downto 0 ) |
| treadmil_data_valid | std_logic |
| treadmil_data_endoffrag | std_logic |
| treadmil_error | std_logic |
| treadmil_stop | std_logic |
| ram_data_output | std_logic_vector ( 31 downto 0 ) |
| ram_data_available | std_logic |
| ram_data_endoffrag | std_logic |
| ram_write_error | std_logic |
| ram_read_error | std_logic |
| rod_data_next | std_logic |
| ram_data_vld | std_logic := ' 0 ' |
| rod_busy_i | std_logic := ' 0 ' |
Component Instantiations | |
| treadmil | bcm_rod_treadmil <Entity bcm_rod_treadmil> |
| treadmill | |
| ram | bcm_rod_ram <Entity bcm_rod_ram> |
| RAM. | |
| formatter | bcm_rod_formatter <Entity bcm_rod_formatter> |
| formatter | |
Detailed Description
structural description of ROD formatterDefinition at line 70 of file bcm_rod.vhd.
Member Data Documentation
bcm_rod_formatter [Component] |
bcm_rod_ram [Component] |
bcm_rod_treadmil [Component] |
formatter bcm_rod_formatter [Component Instantiation] |
ram bcm_rod_ram [Component Instantiation] |
treadmil bcm_rod_treadmil [Component Instantiation] |
