ncm_temac.ncm_temac_arc Architecture Reference

interface to HW MAC More...

Inheritance diagram for ncm_temac.ncm_temac_arc:

Collaboration diagram for ncm_temac.ncm_temac_arc:

List of all members.

Processes

pack ( clk )

trigger readout from FIFO

fillit ( clk , sys_rst )

encode TX data for FIFO and add EMAC control signals

Signals

clk std_logic

sys_rst std_logic

dcm1_locked std_logic

dcm2_locked std_logic

dcm_locked std_logic

tx_fifo_data std_logic_vector ( 31 downto 0 )

tx_fifo_en std_logic

tx_fifo_full std_logic

n_tx_fifo_full std_logic

tx_fifo_lock_n std_logic

rx_fifo_rst std_logic := ' 0 '

rx_fifo_data std_logic_vector ( 31 downto 0 )

rx_fifo_en std_logic := ' 1 '

running std_logic := ' 0 '

good_packet std_logic

gmii_tx_clk_i std_logic

gmii_tx_en_i std_logic

gmii_tx_er_i std_logic

gmii_txd_i std_logic_vector ( 0 to 7 )

gmii_rxd_i std_logic_vector ( 0 to 7 )

gmii_col std_logic := ' 0 '

gmii_crs std_logic := ' 1 '

Component Instantiations

emac0 temac_controller <Entity temac_controller>

ethernet controller

RX auto_receiver <Entity auto_receiver>

RX data decoder.

Detailed Description

interface to HW MAC

Prepares control and data signals for HW MAC

Definition at line 75 of file ncm_temac.vhd.

Member Function Documentation

[Process]

fillit		( clk ,
		sys_rst )

encode TX data for FIFO and add EMAC control signals

Definition at line 218 of file ncm_temac.vhd.

00218   fillit : process(clk, sys_rst)
00219   begin
00220     if (sys_rst = '1') then
00221       running      <= '0';
00222       tx_fifo_data <= x"ffffffff";
00223     elsif rising_edge(clk) then
00224       if EN = '1' then
00225         if EOF = '0' and running = '1' then
00226           running      <= '0';
00227           tx_fifo_data <= x"000000" & DATA_IN;
00228         elsif running = '1' then
00229           tx_fifo_data <= x"000001" & DATA_IN;
00230         elsif SOF = '0' then
00231           running      <= '1';
00232           tx_fifo_data <= x"000001ff";
00233         else
00234           running      <= '0';
00235           tx_fifo_data <= x"ffffffff";
00236         end if;
00237       else
00238         running      <= '0';
00239         tx_fifo_data <= x"ffffffff";
00240       end if;
00241     end if;
00242   end process;

[Process]

pack ( clk )

trigger readout from FIFO

Definition at line 163 of file ncm_temac.vhd.

00163   pack : process(clk)
00164     variable last_good : std_logic               := '0';
00165     variable cnt       : integer range 0 to 1000 := 0;
00166   begin
00167     if (rising_edge(clk)) then
00168
00169       if (cnt = 0) then
00170         if (last_good = '0' and rx_fifo_data(22) = '1') then
00171           cnt         := 999;
00172           good_packet <= '1';
00173         else
00174           last_good   := rx_fifo_data(22);
00175           good_packet <= '0';
00176         end if;
00177
00178       else
00179         last_good := rx_fifo_data(22);
00180         cnt       := cnt - 1;
00181       end if;
00182
00183     end if;
00184   end process;

Member Data Documentation

emac0 temac_controller [Component Instantiation]

ethernet controller

Definition at line 125 of file ncm_temac.vhd.

RX auto_receiver [Component Instantiation]

RX data decoder.

Definition at line 187 of file ncm_temac.vhd.

The documentation for this class was generated from the following file:

ncm_temac.vhd
