busy.busy_arc Architecture Reference
Busy module. More...
Inheritance diagram for busy.busy_arc:
Collaboration diagram for busy.busy_arc:
Processes | |
| mask_trig | ( CLK ) |
| mask triggers | |
Components | |
| edge | <Entity edge> |
| Edge detection. | |
Signals | |
| cnt | std_logic_vector ( 4 downto 0 ) := ( others = > ' 0 ' ) |
| trig_i | std_logic := ' 0 ' |
Component Instantiations | |
| make_edge | edge <Entity edge> |
Detailed Description
Busy module.Busy module for masking triggers with variable deadtime
Definition at line 49 of file busy.vhd.
Member Function Documentation
| mask_trig | ( CLK ) |
mask triggers
Definition at line 66 of file busy.vhd.
00066 mask_trig : process(CLK) 00067 begin 00068 if CLK'event and CLK = '1' then 00069 if RES = '1' then 00070 cnt <= (others => '0'); 00071 else 00072 if TRIG_IN = '1' then 00073 if cnt = DEAD-1 then 00074 trig_i <= '1'; 00075 cnt <= (others => '0'); 00076 else 00077 cnt <= cnt + 1; 00078 trig_i <= '0'; 00079 end if; 00080 else 00081 cnt <= cnt; 00082 end if; 00083 end if; 00084 end if; 00085 end process mask_trig;
Member Data Documentation
edge [Component] |
The documentation for this class was generated from the following file:
