busy Entity Reference

Busy module. More...

Inheritance diagram for busy:

[legend]

Collaboration diagram for busy:

[legend]

List of all members.

Architectures
busy_arc	Architecture
	Busy module. More...
Libraries
ieee
	standard IEEE library
Packages
std_logic_1164
	std_logic definitions, see file
std_logic_arith
	arithmetic operations on std_logic datatypes, see file
std_logic_unsigned
	unsigned functions use ieee.std_logic_unsigned.all; operators for std_logic_vector type, see file
Generics
DEAD	integer range 0 to 30 := 10
	specify deadtime
Ports
CLK	in std_logic
	clock
RES	in std_logic
	reset
EN	in std_logic
	enable
TRIG_IN	in std_logic
	trigger in
TRIG_OUT	out std_logic
	trigger out

---

Detailed Description

Busy module.

Busy module for masking triggers with variable deadtime

Definition at line 34 of file busy.vhd.

---

Member Data Documentation

CLK in std_logic [Port]

clock

Definition at line 39 of file busy.vhd.

DEAD integer range 0 to 30 := 10 [Generic]

specify deadtime

Definition at line 36 of file busy.vhd.

EN in std_logic [Port]

enable

Definition at line 41 of file busy.vhd.

ieee library [Library]

standard IEEE library

Reimplemented in main_components.

Definition at line 24 of file busy.vhd.

RES in std_logic [Port]

reset

Definition at line 40 of file busy.vhd.

std_logic_1164 package [Package]

std_logic definitions, see file

Reimplemented in main_components.

Definition at line 26 of file busy.vhd.

std_logic_arith package [Package]

arithmetic operations on std_logic datatypes, see file

Definition at line 28 of file busy.vhd.

std_logic_unsigned package [Package]

unsigned functions use ieee.std_logic_unsigned.all; operators for std_logic_vector type, see file

Definition at line 30 of file busy.vhd.

TRIG_IN in std_logic [Port]

trigger in

Definition at line 42 of file busy.vhd.

TRIG_OUT out std_logic [Port]

trigger out

Definition at line 43 of file busy.vhd.

---

The documentation for this class was generated from the following file:

• busy.vhd
