edge Entity Reference
Standard rising edge detection. More...
Inheritance diagram for edge:
Collaboration diagram for edge:
Architectures | |
| edge_arc | Architecture |
| Standard rising edge detection. More... | |
Libraries | |
| ieee | |
| standard IEEE library | |
Packages | |
| std_logic_1164 | |
| std_logic definitions, see file | |
| std_logic_arith | |
| arithmetic operations on std_logic datatypes, see file | |
| std_logic_unsigned | |
| unsigned functions use ieee.std_logic_unsigned.all; operators for std_logic_vector type, see file | |
Ports | |
| CLK | in std_logic |
| A | in std_logic |
| PULSE | out std_logic |
Detailed Description
Standard rising edge detection.Standard rising edge detection to provide possibility of detecting a transition in a non-clock signal
Definition at line 35 of file edge.vhd.
Member Data Documentation
ieee library [Library] |
std_logic_1164 package [Package] |
std_logic_arith package [Package] |
std_logic_unsigned package [Package] |
The documentation for this class was generated from the following file:
