statistics Entity Reference
Determines minimum, maximum and average of a series of input values. More...
Inheritance diagram for statistics:
Collaboration diagram for statistics:
Architectures | |
| statistics_arc | Architecture |
| Determines minimum, maximum and average of a series of input values. More... | |
Libraries | |
| ieee | |
| standard IEEE library | |
Packages | |
| std_logic_1164 | |
| std_logic definitions, see file | |
| numeric_std | |
| arithmetic functions use ieee.numeric_std.all; operators for signed use ieee.numeric_std.all; unsigned datatypes, see file | |
Generics | |
| SERIES_LENGTH | integer := 4096 |
Ports | |
| CLK | in std_logic |
| Clock. | |
| RES | in std_logic |
| Reset. | |
| VAL | in std_logic_vector ( 15 downto 0 ) |
| Input value. | |
| MNM | out std_logic_vector ( 15 downto 0 ) |
| Minimum. | |
| MAX | out std_logic_vector ( 15 downto 0 ) |
| Maximum. | |
| AVG | out std_logic_vector ( 15 downto 0 ) |
| Average. | |
Detailed Description
Determines minimum, maximum and average of a series of input values.This entity determines the minimum & maximum value as well as the average of a series of input values. The series length is specified via a generic that needs to be a power of two.
Definition at line 34 of file statistics.vhd.
Member Data Documentation
AVG out std_logic_vector ( 15 downto 0 ) [Port] |
CLK in std_logic [Port] |
ieee library [Library] |
standard IEEE library
Reimplemented in main_components.
Definition at line 24 of file statistics.vhd.
MAX out std_logic_vector ( 15 downto 0 ) [Port] |
MNM out std_logic_vector ( 15 downto 0 ) [Port] |
numeric_std package [Package] |
arithmetic functions use ieee.numeric_std.all; operators for signed use ieee.numeric_std.all; unsigned datatypes, see file
Definition at line 28 of file statistics.vhd.
RES in std_logic [Port] |
std_logic_1164 package [Package] |
std_logic definitions, see file
Reimplemented in main_components.
Definition at line 26 of file statistics.vhd.
VAL in std_logic_vector ( 15 downto 0 ) [Port] |
