ddr_chksum_cal Entity Reference
Running UDP checksum calculation DDR. More...
Inheritance diagram for ddr_chksum_cal:
Collaboration diagram for ddr_chksum_cal:
Architectures | |
| ddr_dsp_chksum_cal_arc | Architecture |
| Running UDP checksum calculation DDR. More... | |
Libraries | |
| ieee | |
| standard IEEE library | |
| unisim | |
| Library with Xilinx primitives. | |
Packages | |
| std_logic_1164 | |
| std_logic definitions, see file | |
| vcomponents | |
| Header with Xilinx primitives. | |
Ports | |
| CLK | in std_logic |
| Clock. | |
| RESET | in std_logic |
| Reset. | |
| EN | in std_logic |
| Enable. | |
| DATA_IN | in std_logic_vector ( 63 downto 0 ) |
| Data input. | |
| WRITE_DONE | in std_logic |
| All data read for this packet. | |
| READ_DATA | in std_logic |
| Get last computed value. | |
| CAL_COMPL | out std_logic |
| Computation done, after asserting Write_done wait until this is high to set EN again. | |
| DATA_OUT | out std_logic_vector ( 15 downto 0 ) |
| last computed value | |
Detailed Description
Running UDP checksum calculation DDR.This entity does a running checksum calculation according to the UDP protocol specification.
Definition at line 36 of file ddr_chksum_cal.vhd.
Member Data Documentation
CAL_COMPL out std_logic [Port] |
Computation done, after asserting Write_done wait until this is high to set EN again.
Definition at line 45 of file ddr_chksum_cal.vhd.
CLK in std_logic [Port] |
DATA_IN in std_logic_vector ( 63 downto 0 ) [Port] |
DATA_OUT out std_logic_vector ( 15 downto 0 ) [Port] |
EN in std_logic [Port] |
ieee library [Library] |
standard IEEE library
Reimplemented in main_components.
Definition at line 25 of file ddr_chksum_cal.vhd.
READ_DATA in std_logic [Port] |
RESET in std_logic [Port] |
std_logic_1164 package [Package] |
std_logic definitions, see file
Reimplemented in main_components.
Definition at line 27 of file ddr_chksum_cal.vhd.
unisim library [Library] |
vcomponents package [Package] |
WRITE_DONE in std_logic [Port] |
