ltp_comm Entity Reference
Interface to LTP (Local Trigger Processor). More...
Inheritance diagram for ltp_comm:
Collaboration diagram for ltp_comm:
Architectures | |
| ltp_comm_arc | Architecture |
| Interface to LTP (Local Trigger Processor). More... | |
Libraries | |
| ieee | |
| standard IEEE library | |
Packages | |
| std_logic_1164 | |
| std_logic definitions, see file | |
Ports | |
| BCLK | in std_logic |
| Bunch Clock. | |
| RESET | in std_logic |
| Reset. | |
| ORBIT | in std_logic |
| Orbit. | |
| BCR | in std_logic |
| Bunch Counter Reset. | |
| START_RUN | in std_logic |
| Start of ATLAS run. | |
| L1A | in std_logic |
| Level-1 Accept. | |
| ECR | in std_logic |
| Event Counter Reset. | |
| ECR_LOAD_EN | in std_logic |
| Enable Load ECR counter. | |
| ECR_LOAD | in std_logic_vector ( 7 downto 0 ) |
| Load ECR counter. | |
| L1A_LOAD_EN | in std_logic |
| Enable Load L1A counter. | |
| L1A_LOAD | in std_logic_vector ( 23 downto 0 ) |
| Load L1A counter. | |
| ORBIT_LOAD_EN | in std_logic |
| Enable Load Orbit counter. | |
| ORBIT_LOAD | in std_logic_vector ( 31 downto 0 ) |
| Load Orbit counter. | |
| EXT_EVID | out std_logic_vector ( 31 downto 0 ) |
| Extended Level-1 Event ID. | |
| BCID | out std_logic_vector ( 11 downto 0 ) |
| Bunch ID. | |
| ORBITID | out std_logic_vector ( 31 downto 0 ) |
| Orbit ID. | |
Detailed Description
Interface to LTP (Local Trigger Processor).This entity combines all modules interfacing to the LTP in a single interface.
Definition at line 32 of file ltp_comm.vhd.
Member Data Documentation
BCID out std_logic_vector ( 11 downto 0 ) [Port] |
BCLK in std_logic [Port] |
BCR in std_logic [Port] |
ECR in std_logic [Port] |
ECR_LOAD in std_logic_vector ( 7 downto 0 ) [Port] |
ECR_LOAD_EN in std_logic [Port] |
EXT_EVID out std_logic_vector ( 31 downto 0 ) [Port] |
ieee library [Library] |
L1A in std_logic [Port] |
L1A_LOAD in std_logic_vector ( 23 downto 0 ) [Port] |
L1A_LOAD_EN in std_logic [Port] |
ORBIT in std_logic [Port] |
ORBIT_LOAD in std_logic_vector ( 31 downto 0 ) [Port] |
ORBIT_LOAD_EN in std_logic [Port] |
ORBITID out std_logic_vector ( 31 downto 0 ) [Port] |
RESET in std_logic [Port] |
START_RUN in std_logic [Port] |
std_logic_1164 package [Package] |
std_logic definitions, see file
Reimplemented in main_components.
Definition at line 27 of file ltp_comm.vhd.
The documentation for this class was generated from the following file:
