delay.delay_arc Architecture Reference

Delay unit. More...

Inheritance diagram for delay.delay_arc:

[legend]

Collaboration diagram for delay.delay_arc:

[legend]

List of all members.

Processes
delay_signal	( CLK )
	Counter for delay adjust.
Signals
shift	std_logic_vector ( 99 downto 0 ) := ( others = > ' 0 ' )

---

Detailed Description

Delay unit.

Definition at line 44 of file delay.vhd.

---

Member Function Documentation

[Process]

delay_signal

( CLK )

Counter for delay adjust.

Definition at line 51 of file delay.vhd.

  delay_signal : process(CLK)
  begin
    if CLK'event and CLK = '1' then
      if RES = '1' then
        shift <= (others => '0');
        A_DEL <= '0';
      else
        shift <= shift(98 downto 0) & A;
        A_DEL <= shift(i);
      end if;
    end if;
  end process delay_signal;

---

The documentation for this class was generated from the following file:

• delay.vhd
