GT11_INIT_RX Entity Reference
Initializer for RocketIO RX. More...
Inheritance diagram for GT11_INIT_RX:
Collaboration diagram for GT11_INIT_RX:
Architectures | |
| rtl | Architecture |
| Initialization logic for RocketIO RX. More... | |
Libraries | |
| ieee | |
| standard IEEE library | |
| unisim | |
| Library with Xilinx primitives. | |
Packages | |
| std_logic_1164 | |
| std_logic definitions, see file | |
| numeric_std | |
| arithmetic functions use ieee.numeric_std.all; operators for signed use ieee.numeric_std.all; unsigned datatypes, see file | |
| vcomponents | |
| Header with Xilinx primitives. | |
Generics | |
| C_SIMULATION | integer := 0 |
| Set to 1 for simulation. | |
Ports | |
| CLK | in std_logic |
| Clock. | |
| START_INIT | in std_logic |
| Start of init flag. | |
| LOCK | in std_logic |
| PLL lock flag. | |
| USRCLK_STABLE | in std_logic |
| Clock stable flag. | |
| PCS_ERROR | in std_logic |
| PCS error flag. | |
| PMA_RESET | out std_logic |
| PMA reset. | |
| SYNC | out std_logic |
| Syncronization flag. | |
| PCS_RESET | out std_logic |
| PCS reset. | |
| READY | out std_logic |
| Done flag. | |
Detailed Description
Initializer for RocketIO RX.Definition at line 57 of file gt11_init_rx.vhd.
Member Data Documentation
C_SIMULATION integer := 0 [Generic] |
CLK in std_logic [Port] |
ieee library [Library] |
LOCK in std_logic [Port] |
numeric_std package [Package] |
arithmetic functions use ieee.numeric_std.all; operators for signed use ieee.numeric_std.all; unsigned datatypes, see file
Definition at line 47 of file gt11_init_rx.vhd.
PCS_ERROR in std_logic [Port] |
PCS_RESET out std_logic [Port] |
PMA_RESET out std_logic [Port] |
READY out std_logic [Port] |
START_INIT in std_logic [Port] |
std_logic_1164 package [Package] |
SYNC out std_logic [Port] |
unisim library [Library] |
USRCLK_STABLE in std_logic [Port] |
vcomponents package [Package] |
The documentation for this class was generated from the following file:
